FLIR Thermal Imaging Camera E6 Pro WiFi MSX 240 x 180 Resolution with Bonus Training and Warranty Pack

$3,740.00

Select Section

Overview

Intro:
The FLIR E6 Pro WiFi MSX is a professional thermal imaging camera designed for fast identification of faults in electrical, building, HVAC and mechanical systems. It combines 240 x 180 thermal resolution with MSX image enhancement for clear diagnostic imaging and efficient reporting.

Key Benefits:

High resolution 240 x 180 thermal imaging improves fault detection accuracy
MSX technology enhances visual detail for easier problem identification
Wide temperature range supports industrial and building inspection work
WiFi connectivity enables instant image transfer and reporting
Touchscreen interface simplifies inspection workflow and documentation

Applications:

Electrical fault detection and switchboard inspections
HVAC system diagnostics and airflow leakage checks
Building envelope inspections for moisture and insulation issues
Mechanical equipment condition monitoring
Preventative maintenance and compliance reporting

Features:

Thermal resolution: 240 x 180 (43,200 pixels)
Thermal sensitivity: <0.06°C / <50 mK at 30°C
Accuracy: ±2°C or ±2% of reading (10°C to 35°C ambient)
Temperature range: -20°C to 550°C (-4°F to 1022°F)
Field of view: 33° x 25°
Image modes: Thermal MSX, Thermal, Picture-in-Picture, Visual
Display: 3.5 inch 640 x 480 colour LCD touchscreen
Digital camera: 5 MP integrated visual camera
Image frequency: 9 Hz
Focus: Focus free
Minimum focus distance: 0.36 m
Storage: Internal memory with FLIR Ignite cloud connectivity
Connectivity: WiFi 802.11 a/b/g/n (2.4 and 5 GHz)
Spot meter: centre spot with min/max box measurement
Isotherm and Delta T functions (NFPA 70B compliant)
Emissivity and reflected temperature correction settings

Specifications:

IR resolution: 240 x 180 pixels (43,200 pixels)
Detector type: uncooled microbolometer
Spectral range: 7.5 to 13 µm
Spatial resolution (IFOV): 2.5 mrad
Camera size: 244 x 95 x 140 mm
Weight (including battery): 0.590 kg
Display: 3.5 inch 640 x 480 colour LCD
Battery type: rechargeable lithium ion
Operating temperature range: -15°C to 50°C
Storage temperature range: -40°C to 70°C
Humidity: IEC 60068-2-30, up to 95% RH
Protection rating: IP54
Drop test: 2 m
Shock: 25 g
Vibration: 2 g
Charging time: 2 hours
Battery operation: 4 hours
Package includes: infrared camera, hard case, battery, charger with AU/UK/EU/US plugs, FLIR Thermal Studio Starter, documentation

Why Choose This Product:
Ideal for professionals who require reliable thermal diagnostics with higher resolution, cloud reporting capability, and rugged field performance for daily inspection and maintenance work.
